Trend LOCK/JIG/C Professional Lock Jig

Description

• Product Code:TRELOCKJIGC

• Model Number: LOCK/JIG/C

• Brand: Trend

• Barcode: 5027654091500

• Category: Door Hinge & Lock Jigs

• Taxonomy: Hardware > Tool Accessories > Jigs

If you’re regularly fitting locks, the Trend LOCK/JIG/C Professional Lock Jig from ITS is going to make your life a whole lot easier.

Built tough with solid steel, this professional lock jig is designed to deliver precision and consistency every time you route a lock or faceplate recess. Whether you're on site or in the workshop, it gives you full control, thanks to the long adjustable fence and smooth clamp system.

The jig adapts easily to doors between 34mm and 58mm thick, and those thumb-turn clamps mean setup is quick and frustration-free - no more messing with tools just to get things in place. It comes with 17 templates to cover all the common lock sizes, and the centring insert makes sure you're always spot on when lining up.

Plus, the guide bush collar and height spacers speed things up even more by cutting down on extra measuring and fiddling. If you’re using a ½” router with an 80mm plunge and a 12mm cutter, you’re good to go.

This jig’s all about getting the job done faster, with less hassle, and with results that look professional every time.

Faceplate Templates:

25.4 x 60.0mm (Tubular Latch) - 22(A)
24.0 x 57.5mm (Tubular Latch) - 22(B)
26.0 x 56.5mm (Tubular Latch) - 23(A)
26.0 x 57.5mm (Tubular Latch) - 23(B)
22.2 x 128.5mm - 20
22.2 x 155.0mm - 1
22.5 x 152.5mm - 2
25.4 x 121.0mm - 3
26.0 x 134.0mm - 5
25.4 x 153.0mm - 7
25.4 x 165.5mm - 9
25.4 x 177.0mm - 10
26.0 x 139.0mm - 21
26.0 x 162.0mm - 12

Mortise Templates:

19 x 22mm (Tubular Latch) - J(A)
22 x 24mm (Tubular Latch) - J(B)
16 x 72mm - A
16 x 102mm - F
16 x 109mm - B
19 x 78mm - C
19 x 90mm - E
19 x 109mm - D
19 x 115mm - H

Requires: ½”/12mm Plunge Router (80mm plunge depth), ½”/12mm Router Cutter (12mm cut diameter x 63mm cut length), and 30mm Guide Bush.

---
