The Leica LINO L2G+ Kit with Tripod, Target Plate, Multifunction Adapter, 4 NiMH Batteries, Carry Case and Pouch.
Best-in-class visibility with new green beam technology!
The Leica Lino L2G+ cross line laser projects highly visible lines at right angles to one another. This new laser uses the latest green laser technology, making the lines more visible and clear. Plain and simple, this laser will make it easier for you to see your reference line. Even with this new technology you can still get 7 hours out of one set of batteries
Time-consuming & tedious drawing lines on the wall is a thing of the past. The Leica Lino (L2PLUSG) projects them exactly, quickly & easily, allowing you to concentrate on the job in hand. The improved emergence angle ensures outstanding visibility & extension of the laser lines & allow perfect leveling & alignment at long distances.
Emergence angle of 180°, Pulse function with power-saving mode, Modern, ergonomic housing, Exact 90° angle, Very easy to use.
Green laser beams are up to four times more visible to the human eye. So it is much easier to see, especially in very bright conditions or over distances, both of which are common on job sites.
Self-levelling - The instrument is set up quickly and effortlessly to project horizontal or vertical lines. Minor angular mis-alignments of ± 4° are compensated automatically. If the tilt is outside these limits, the device does not project any lines and errors are therefore prevented.
Extra long laser lines - The improved emergence angle ensures outstanding visibility and extension of the laser line for perfect levelling and alignment at long distances. It is possible, e.g., to transfer reference points from one wall to the next. Leave your spirit level and string in your tool box.
Working in bright conditions - The pulse function is not just an energy-saving mode: it also allows you to locate the laser lines using a laser detector, even in very bright lighting conditions. A series of acoustic signals from the detector indicates the precise position of the laser beam plane.
Lock function - You can manually switch off the self-levelling features using the lock function. The laser line can then be projected at any angle. The lock function also serves as transport protection.
Best-in-class laser line visibility
Projects clear, crisp laser lines
Horizontal, vertical and cross lines
180° horizontal fan angle
Accuracy ± 1.5 mm @ 5 m
Lock function for any inclination
7 hours working time with only one set of batteries
Range: Up to 30m depending on lighting conditions.
Levelling accuracy: ± 1.5mm at 5m
Self-levelling range: 4° ± 0.5°.
Accuracy of horizontal line: : ± 1.5 mm at 5m.
Vertical accuracy: ± 1.5mm at 3m line length.
Horizontal fan angle: 180°.
Laser type: 515-520 nm, laser class II.
Batteries: Type AA 4 × 1.5 V
Working time per battery set: 7 Hours.
Protection class splash water/dust proof: IP54.
Dimensions (H × D × W): 117.8 × 130.7 × 75.4 mm.
Weight without batteries: 370g.
Tripod Screw: ¼”.
Simply perfect all along the line.
The LEI2PLUSGKIT come supplied with:
- Leica LINO L2G+
- Target Plate,
- Multifunction Adapter,
- 4 NiMH Batteries,
- Carry Case
